Max Horizontal Load 000 Kg Pneumatic Indexing Rotary Table
Featuring Manual Rotary Drive and Indexing Accuracy ±2 Seconds 72 Divisions for Operation
Product Overview
The Pneumatic Indexing Rotary Table is an advanced air-powered indexing solution designed to deliver precise and efficient rotary positioning in various industrial applications. Built from high-quality aluminum alloy, this robust rotary table guarantees durability and long-lasting performance while maintaining a lightweight structure for easy integration into existing systems.
The design emphasizes versatility, accommodating a wide range of operational needs with its variable table sizes and load capacities. With total heights spanning from 130 mm to 340 mm and table sizes ranging from 300×300 mm to 1200×1200 mm, this equipment provides optimal configuration options for diverse project scales.
Engineered to handle substantial loads, the Pneumatic Indexing Turntable Device boasts a maximum vertical load capacity ranging from 1,200 kg up to 7,000 kg, making it ideal for heavy-duty tasks including machining, assembly, inspection, and manufacturing processes where precision and reliability are crucial.
Key Features
- Product Name: Pneumatic Indexing Rotary Table
- Material: High-quality Aluminum Alloy
- Max. Horizontal Load: 500 Kg to 6,000 Kg (model-dependent)
- Table Size: Square series from 300×300 mm to 1200×1200 mm
- Indexing Accuracy: ±3 seconds for 360° full indexing and ±2 seconds for 72 divisions
- Clamping: Pneumatic lock/unlock mechanism with air supply requirement of 5-8 Kg/cm²
- Air-operated indexing mechanism for precise and efficient operation
Technical Specifications
| Key Benefits |
Heavy-cut Capable, Durable, Low-maintenance, Long-term Stability |
| Construction |
FC-35 Cast Iron Body With Stress-relief Heat Treatment |
| Drive Type |
Pneumatic |
| Flatness / Runout |
0.01-0.03 Mm Precision Range Across The Series |
| Type |
Rotary Table |
| Max. Horizontal Load |
500 Kg To 6,000 Kg (model-dependent) |
| Positioning System |
2-piece Hirth Coupling, Zero Accuracy Drift Over Time |
| Application |
High-precision Machining (boring, Milling, Grinding) |
| Rotation Direction |
Bi-directional (clockwise / Counterclockwise) |
| Total Height |
130 Mm To 340 Mm |
Applications
The JuZhuo Pneumatic Indexing Rotary Positioner, model HCT Series, is designed for precision applications in automated assembly lines, CNC machining centers, welding stations, and robotic workcells. Its exceptional indexing accuracy of ±3 seconds for full 360° indexing and ±2 seconds for 72 divisions ensures precise and repeatable positioning critical for automated manufacturing processes.
Typical applications include gear cutting, drilling, inspection, packaging, automotive manufacturing, aerospace component production, electronics assembly, and metal fabrication. The pneumatic drive mechanism provides smooth, reliable rotation powered by compressed air, making it a cost-effective and low-maintenance solution suitable for factories with existing pneumatic infrastructure.
Customization Options
JuZhuo offers customized Pneumatic Indexing Rotary Positioner solutions with the HCT Series, certified with ISO9001 and CE. We cater to various customer requirements with a minimum order quantity of just 1 set, and pricing is negotiable to suit your project needs.
Our supply capability reaches up to 1000 sets per month, meeting both small and large-scale demands. Each unit is carefully packaged in durable wooden boxes to ensure safe delivery, with flexible delivery times arranged according to customer requirements.
Support & Services
Our technical support team is dedicated to assisting with installation, operation, and troubleshooting to ensure optimal performance. Services include guidance on setup procedures, maintenance schedules, calibration techniques, and integration advice for compatibility with existing pneumatic systems and automation controls.
We provide detailed documentation, user manuals, and replacement parts to keep your equipment running smoothly. Regular inspections and preventative maintenance are recommended to prolong the lifespan of your rotary table.
Packaging & Shipping
The Pneumatic Indexing Rotary Table is carefully packaged with protective foam and plastic film to prevent damage during transit. Units are securely placed in sturdy wooden crates or reinforced cardboard boxes, clearly labeled with handling instructions.
We offer multiple shipping options including air freight, sea freight, and express courier services. All international shipments include necessary documentation for smooth customs clearance, ensuring timely and safe delivery to your specified destination.
