Sectional Automatic Check Weigher Machine Weight Checker Equipment System JZ-W Series

Name: Sectional Automatic Check Weigher Machine Weight Checker Equipment System JZW Series
Brand: JUZHUO
Price: 1 USD

Buy cheap Sectional Automatic Check Weigher Machine Weight Checker Equipment System JZ-W Series product

conveyor speed : 3-15m/minutes

Power Supply : 220V

Brand Name : JUZHUO

Model Number : JZ-W100800

HBM load cell : (original from Germany)

waterproof : IP66

Place of Origin : Guangdong, China

display type : 10" color touch screen

machine material : SUS304

accuracy : +/-10grams

MOQ : 1

Contact Now

High Quality Automatic Check Weigher / Weight Checker / Weight Checking Machine

Automatic Check Weigher / Weight Checker / Weight Checking Machine

Application

Check Weigher JZ-W100800 is used to check whether the single pack weight conforms to the preset weight. Overweight and underweight products can be automatically removed by various reject devices, while qualified bags are passed to the next equipment.

Features

PLC and 10" color touch screen with intelligent compact design construction
Auto program setting adjustment for enhanced stability and easier operation
HBM load cell ensures high accuracy and stability (original from Germany)
Solid SUS304 structure provides stable performance and precise weighing
Multiple reject options: reject arm, air blast, or pneumatic pusher
Tool-free belt disassembly for easier cleaning
Emergency switch installation for user-friendly operation
Arm device clearly displays production situation (optional)
Can record up to 10 different product parameters
Intelligent compact design construction with auto program setting adjustment

Specifications

Model	JZ-W100800
Control System	10" color touch screen
Weighing Range	1000-100000 grams
Conveyor Speed	3-15 meter/min
Maximum Throughput Capacity	20 bags/min
Accuracy	±10 grams
Mini Scale	1 gram
Weigh Belt	1000L * 800W mm
Conveyor Height	750mm ±50mm
Auto Reject System	Reject Arm / Air Blast / Pneumatic Pusher / Divided-flow Style
Grade of Waterproofing	IP66
Power Supply	220V/50HZ or 60HZ Single Phase
Machine Material	304 stainless steel
Interface	Transmit weight to Ink-jet printer (requires customer protocol)
Packing Dimension	2000L * 850W * 1600H mm
Gross Weight	400 KG

Optional Parts

Software for network data management
Front feeding FBC feedback control software
Printer
Lamp
