Worm Gear 4 Axis Rotary Table Tailstock For CNC Router Engraver Milling Machine

Name: Worm Gear 4 Axis Rotary Table Tailstock For CNC Router Engraver Milling Machine
Brand: Juzhuo
Price: 1 USD

Buy cheap Worm Gear 4 Axis Rotary Table Tailstock For CNC Router Engraver Milling Machine product

video outgoing-inspection : Provided

Marketing Type : Hot Product 2019

Center through hole : 70H7

Horizontal loading capacity : 250kg

Applicable Industries : Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising C

Place of Origin : Guangdong, China

Center height(mm) : 160

Structure : Worm gear

division precision : +/-10

vertical loading capacity : 100Kg

Name : 4 Axis Rotary Table

Rotary Table Diameter : 255

usage : milling or drilling machine

Showroom Location : Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Vietnam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, India, Mexico, Russia, Spain, Thailand, Morocco, Kenya, Argentina, South Korea, Chile, UAE, Colombia, Alger

warranty : 3 Years

material : steel

Brand Name : Juzhuo

machinery test report : Provided

weight (kg) : 100

Core Components : PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear, Pump

MOQ : 1

Contact Now

Best Selling 4 Axis Rotary Table Tailstock and Rotary Table 4th Axis for CNC Router Engraver Milling Machine

Model: D-255 - Professional 4-axis CNC rotary table system designed for precision machining applications.

Product Characteristics

Utilizes imported precision dual-lead worm and turbine system with aluminum bronze alloy construction, ensuring high-precision transmission and positioning accuracy
Turbine size nearly matches disc dimensions with steel rigidity improved by 30-50% compared to similar products
Features cross roller bearings that enhance rotation accuracy and rigidity, enabling long-term processing operations without workpiece defects

Technical Specifications

Worm Gear 4 Axis Rotary Table Tailstock For CNC Router Engraver Milling Machine
